Smart-P300U

Work field-oriented brilliant handheld computer

Hand-sized design and light weight device with high capacity memory and upgraded CPU helps our customers to obtain better competence at work place.

Smart-P300Us work place-centered design with light weight and comfortable gripper will perfectly support long-period operation.



RFID Module, which is optional, is designed for UHF (865~928MHz), reading range of -~500cm (subject tag)



Smart-P300U UHF Ruggedized Handheld Computer





Display

3.5" Touch Screen 350 NIT

240 x 320 QVGA (Option 480 x 640 VGA)



Environment

Operating Temperature : -20 to 60 C (-4 to 140 F)

Storage Temperature : -30 to 75 C (-22 to 167 F)

Humidity : 10% to 90% (non-condensing)

Environmental Protection : IP54



Memory and Storage

ROM, NAND Flash 512MB (Optional 2GB)

RAM, mDDR, 256MB



Microprocessor

Marvel PXA-320 806MHz



Operating System

Microsoft WinCE 5.0 (Optional : Windows Mobile 6.5)



Network Characteristics

Communication - HSUPA (WCDMA) / EDGE / GSM / GPRS



Bluetooth (Ver 2.0 + EDR)

A-GPS

WLAN - 802.11b/g/n (Optional 802.11 a/b/g)



Interfaces

(1) Micro SD slot

(1) USIM slot

Numeric 32 Keys (Optional : QWERTY 43keys)

Hands Free Speaker, Microphone/ Receiver / Headset Port

USB ver 2.0 Host, RS232 interface (Connecter Option)



Barcode Scanning

1D (Optional 2D)



Camera

3.0M Pixel with Flash



RFID Module (Optional)

HF (13.56MHz)

- ISO 14443 A/B, ISO 15693, Mifare / - Reading Range 0~6cm



Battery

4000mAH + Gun 2,600mAH

Charging Time : 5h



Dimensions

75 x 129 x 174 mm

Weight : 2.7kg (5.9lbs.)



Power

AC/DC Converter input 110/220V AC



Certifications

FCC, KC, CE
