RFID Tags

SmartTag Fastener

SmartTag Fastener is the best performing tag among

SmartTags with stable read performance on both metal and non-metal.


SmartTag Fastener for Unparalleled Robust Metal Mounting Solution


Dimensions

Length 148mm (5.8 in.) / Width : 18.2mm (0.7 in.) / Tahickness : 3.2mm (0.12 in.) / Hole diameter : 5.5mm (0.2 in.)



Memory and Storage

96 up to 480 bits EPC, 64 bit TID, 512 bit programmable user memory

Read Range

Fixed reader : On non-metal 8.0m / On metal 7.0m
Handheld reader : On non-metal 3.0m / On metal 2.5m


Environment

Humidity :
5 % to 95 % RH Non-condensing
Vibration and Shock protection :
Withstands standard material handling vehicle environments.
Meets or Exceeds MIL STD 810 F
IEC60068-2-6/64 (Vibration), IEC60068-2-31 (Drop&Topple), IEC60060-2-11 (Salt water)
Thermal Cycling :
-45 to 85 C
Environmental Protection : Sealed to IP68 (water and dust tight)
